Setup
Ethernet Test Set 47
Remote Selection
An icon will be displayed in the title bar if the Loop Up or the Connect
operation is successful.
5. For Remote Loopback, any test/tool can be started at this time.
For DTS RFC 2544, only the RFC 2544, Ping and Trace Route tests/tools
can be started.
6. To loop down or disconnect, press the down arrow to highlight the
Loop Down or Disconnect button respectively for Remote Loopback
or DTS RFC 2544.
7. Press the button to select the Loop Down or Disconnect button to
disable the Smart Loopback or DTS RFC 2544 mode from the target
module. Loop down or Disconnect is possible only following a
successful loop up or connect process on a selected target module.
Note: Even if a remote module is busy, it can still be overtaken by the Loop Up or
Connect command.
The possible statuses of the remote module are as follows:
Status Description
Idle No tests are running.
Looped Up Smart Loopback mode has been started using
Remote Loopback.
Smart Loopback Smart Loopback mode has been started
manually.
Busy No tests are running but the module is busy.
Busy-BERT BERT testing is running.
Busy-Traffic Gen Traffic Generation & Monitoring test is running.
Busy-RFC 2544 RFC 2544 test is running.
Busy-Ping Ping test is running.
Busy-Trace Route Trace Route test is running.
