Configuring and Starting a Test or Tool
Ethernet Test Set 29
Configuring a Traffic Generation & Monitoring Test
Configuring a Traffic Generation & Monitoring
Test
To configure the Traffic Generation & Monitoring Test (Stream
Config):
1. Configure the interface by configuring the port, network, and VLAN
settings. Refer to Interface on page 33. Ensure that the link is up
(indicated by the platform LED) before proceeding to the next step.
2. Optionally set a remote module in loopback. Refer to Remote Selection
on page 45.
3. Press , select Traffic Generation & Monitoring, Stream Config,
and the Global tab.
4. Configure the global settings by referring to Global Configuration on
page 125.
5. Select the Shaping tab and configure the shaping settings by referring
to Shaping Configuration on page 128.
6. Select the Stream tab and configure the stream settings by referring to
Stream Configuration on page 130.
7. Select the Sequence tab and configure the sequence settings by
referring to Sequence Configuration on page 134.
8. Select the Jitter/Latency tab and configure the Jitter/Latency settings
by referring to Jitter/Latency Configuration on page Jitter/Latency
Configuration on page 136.
