Traffic Generation & Monitoring
138 AXS-200/850
Jitter/Latency Configuration
For IPv6:
³
Jitter Pass/Fail Verdict: Enable Jitter Pass/Fail Verdict to display Jitter
Pass/Fail Verdict on Jitter/Latency results page.
Threshold: When the Jitter Pass/Fail Verdict is enabled, Threshold
value can be set in milliseconds. Jitter Pass/Fail Verdict is declared as
PASS when the maximum jitter value is smaller than or equal to the
threshold. Jitter Pass/Fail Verdict is declared as FAIL when the
maximum jitter value is greater than the threshold.
Jitter pre-defined
profile
Supporting speed Frame size Transmit rate
VoIP G.711 10/100/1000 Mbps 158 Bytes 0.1424 Mbps
VoIP G.723.1 10/100/1000 Mbps 102 Bytes 0.032533 Mbps
VoIP G.729 10/100/1000 Mbps 98 Bytes 0.0472 Mbps
IPTV SDTV (MPEG-2) 10/100/1000 Mbps 1394 Bytes 4.029255 Mbps
IPTV HDTV (MPEG-2) 100/1000 Mbps 1394 Bytes 20.833936 Mbps
IPTV HDTV (MPEG-4) 100/1000 Mbps 1394 Bytes 10.744681 Mbps
