Traffic Generation & Monitoring
158 AXS-200/850
Summary Results
³
Frame size (Bytes): Set the frame size for Ethernet and
Ethernet/IPv4/UDP or Ethernet/IPv6/UDP frame structure. The default
value for Ethernet/IPv4/UDP framing mode is 64 bytes. The default
value for Ethernet/IPv6/UDP framing mode is 70 bytes. The minimum
frame size varies with the framing selection and the number of VLAN
layers configured.
The following table displays the minimum and maximum frame size:
Frame
Type
Minimum Frame Size (Bytes)
Maximum
Frame Size
(Bytes)
Jitter Yes No
Latency Yes No Yes No
Sequence
Tracking
Yes No Yes No Yes No Yes No
Ethernet No VLAN 98 84 84 70 80 66 66 48 9600
One VLAN 102 88 88 74 84 70 70 48 9600
Two VLAN 106 92 92 78 88 74 74 48 9600
Ethernet
/IPv4/UDP
No VLAN 98 84 84 70 80 66 66 52 9600
One VLAN 102 88 88 74 84 70 70 56 9600
Two VLAN 106 92 92 78 88 74 74 60 9600
Ethernet
/IPv6/UDP No VLAN 118 104 104 90 100 86 86 72 9600
One VLAN 122 108 108 94 104 90 90 76 9600
Two VLAN 126 112 112 98 108 94 94 80 9600
