EXFO AXS-200/850 Ethernet Test Set - Manual (Page 89)

RFC 2544
Ethernet Test Set 79
Summary Results
Report Generation
Reports can be generated for the test and tools results. The report button is
available on the BERT, Traffic Generation & Monitoring, RFC 2544
summary tabs, and Ping, Trace Route, and Cable Test result tabs.
To generate a report:
1. Select the Report button from the
Results page, if not already
selected, and press the button.
2. The report is being generated and
is displayed on screen.
3. Press the button to select the
report section, and use the up and
down arrows to scroll through the
report.
4. Press the button to have access to the function keys.
5. Press Bottom to move to the bottom of the page.
Note: When the bottom of the page is displayed, Bottom changes to Top.
Report button
