Traffic Generation & Monitoring
Ethernet Test Set 151
Default Gateway
Default Gateway
The Default Gateway tab allows the configuration of the default gateway
address to forward packets outside the subnet.
Press , select Traffic Generation & Monitoring, Background Stream
Config, and the Default Gateway tab.
Note: The Default Gateway tab is only available when the selected IP version is
IPv6. See IP Version on page 37 to select IPv6 version
³
Background Stream: Select any
of the three background streams
for which the network
parameters are to be configured.
³
Mode:
Automatic allows automatic
selection of the default
gateway. The default setting
is Automatic.
Static allows entering the default gateway IP address.
³
Address: If the Mode is Static, enter the IP address of the Default
Gateway. The accepted range is from
FE80:0000:0000:0000:0000:0000:0000:0000 to
FE80:0000:0000:0000:FFFF:FFFF:FFFF:FFFF. The default address
is FE80:0000:0000:0000:0000:0000:0000:0000. When the Mode
is Automatic, the address field is not configurable.
