Traffic Generation & Monitoring
124 AXS-200/850
The Traffic Generation & Monitoring test offers the following structure:
SubMenu Tab Page
Stream Config: The Stream Config allows
configuring main stream and global test
properties.
Global Configuration 125
Shaping Configuration 128
Stream Configuration 130
Sequence Configuration 134
Jitter/Latency Configuration 136
Background Streams Config: The
background streams are available through
a software option. When the Multiple
Streams software option is enabled, up to 3
background streams are generated. The
three background streams have individual
Transmit, Stream, Network, Default
Gateway, and VLAN configuration.
Transmit Configuration 140
Stream Configuration 130
Network Configuration 147
Default Gateway 151
VLAN Configuration 153
Results: Result page allows user to not only
view the status of the test, but also to
change certain parameters dynamically as
the test is running.
Summary Results 154
Throughput Results 163
Sequence Results 165
Jitter/Latency Results 169
Alarms/Errors Results 171
Frame Count Results 174
Frame Size Results 175
Flow Control Results 177
Logger: Logger page allows you to
configure and view the list of recorded
events with the history of the events
recorded while a test case was running,
including threshold crossing events.
Logger 178
