System
212 AXS-200/850
File Manager
File Manager
The File Manager allows files and folders to be copied or deleted from the
AXS-200/850 Ethernet Test Set module. Files and folders can be transferred
to and from an external USB media.
To transfer files to and from the USB port:
1. Press ,
select System, Utilities, and the File Manager page.
2. Select the desired file or folder as
follows:
2a. Select the media where the
file is located.
2b. Select the folder where the
file is located.
2c. Use the down arrow to
highlight the list of files and
press the
button to select the list.
³
Use the up/down arrows to navigate in the list. To open a folder,
highlight it, then select Open Folder on the bottom of the screen
using the corresponding function key.
³
Once on the desired file, select Sel./Unsel. or select them all with
Sel./Unsel All using the corresponding function key.
3. Use the function arrows to go to the next available options, and select
Copy using the corresponding function key.
4. Paste the file or folder as follows:
4a. Find the destination folder in the same manner to find the copy
folder.
4b. Use the function arrows to go to the next available options, and
select Paste using the corresponding function key.
5. To exit the list box, press the button.
