Traffic Generation & Monitoring
176 AXS-200/850
Frame Size Results
The following table displays the received frame size count statistics:
Frame size Description
<64 The total number of frames received with an
Ethernet frame size smaller than 64 bytes
64 The total number of frames received with an
Ethernet frame size of 64 bytes
65-127 The total number of frames received with an
Ethernet frame size greater than 64 bytes but
smaller than 128 bytes
128-255 The total number of frames received with an
Ethernet frame size greater than or equal to
128 bytes but smaller than 256 bytes
256-511 The total number of frames received with an
Ethernet frame size greater than or equal to
256 bytes but smaller than 512 bytes
512-1023 The total number of frames received with an
Ethernet frame size greater than or equal to
512 bytes but smaller than 1024 bytes
1024-1518 The total number of frames received with an
Ethernet frame size greater than or equal to
1024 bytes but smaller than or equal to 1518 bytes
>1518 The total number of frames received with an
Ethernet frame size greater than 1518 bytes
Total The total number of frames received
