Configuring and Starting a Test or Tool
Ethernet Test Set 31
Configuring a Smart Loopback Test
Configuring a Smart Loopback Test
To configure the Smart Loopback test:
1. Configure the interface by configuring the port, network, and VLAN
settings. Refer to Interface on page 33. Ensure that the link is up before
proceeding to the next step.
2. Press , and select Smart Loopback.
3. The test can be started from this page and the statistics are displayed
on the same page.
4. Press to start or stop the test.
Configuring a Ping Tool
To configure the Ping tool:
1. Configure the interface by configuring the port, network, and VLAN
settings. Refer to Interface on page 33. Ensure that the link is up before
proceeding to the next step.
2. Press , select Tools, Ping, and the Ping Configuration tab.
3. Configure the Ping tool by referring to Ping Configuration on page 186.
4. Press to start or stop the tool.
