Setup
Ethernet Test Set 37
Network
Network
The Network tab allows the configuration of the Ethernet port parameters.
Press , select Setup, Interface, and the Network tab.
To configure the Network settings:
Note: The source MAC Address field is fixed and is not configured.
1. Select the IP Version. Choices are IPv4 and IPv6. By default, IPv4
option is selected.
Note: The IP Version field is configurable only when the IPv6 software option is
activated in the System, Software Options - Module tab.
If IPv4 option is selected as the IP version, configure the remaining fields as
below.
2. Enable or disable the DHCP.
Note: If DHCP is enabled, all parameters are
set to the values obtained through
DHCP.
Note: If DHCP is disabled, IP Address and
Subnet Mask fields become
configurable. When DHCP is enabled,
the Default Gateway is automatically
obtained from DHCP.
3. Configure the IP Address. The default IP address is 10.10.0.0. When
the IP Address field is selected for editing, the Latest IP’s button
appears on the bottom of the screen. Press the corresponding function
key to display the list of previously configured IP addresses. Select the
desired IP address from the list, if any.
