RFC 2544
74 AXS-200/850
Latency Configuration
³
Maximum Rate: Enter the Maximum Rate as a percentage of the line
rate or in Mbps. The accepted values are as follows:
³
Copy from Throughput Test: Enable to get values from the
Throughput subtest results. This setting is enabled by default. When
the Copy from Throughput Test parameter is enabled, the
Throughput subtest results will be used as the Maximum Rate
individually for each corresponding frame size.
³
Verdict Threshold: Set the threshold value as the maximum delay in
ms. If the determined latency value is less than or equal to the
threshold value, the test is declared as PASS. If the determined latency
value is higher than the threshold value, the test is declared as FAIL.
The accepted range is 0.015 to 8000 ms with a default value of 125 ms,
and this value applies to all the 7 RFC 2544 frame sizes or for the 7
user-defined frame sizes.
Interface Maximum Rate
Speed % Mbps
10 Mbps 0.1 - 100,
default = 100 0.01 - 10, default = 10
100 Mbps 0.1 - 100, default = 100
1000 Mbps 1 - 1000, default = 1000
