Traffic Generation & Monitoring
Ethernet Test Set 141
Transmit Configuration
The following table displays the minimum and maximum frame size:
³
Payload: Set the Payload of the frames in hexadecimal format. The
accepted range is from 00 to FF. The default value is CC.
³
TX Rate: Set the transmission rate in terms of a percentage of the line
rate or in Mbps.
³
Total TX Rate: The Total TX Rate indicates the sum of the transmit rate
of all streams enabled for transmission.
³
Copy Main Stream to All Backgrounds: Select the Copy Main Stream
to All Backgrounds button to copy main stream and interface setup
configuration parameters to background streams configuration.
Frame Type
VLAN
Configuration
Minimum
Frame Size
(Bytes)
Maximum
Frame size
(Bytes)
Ethernet No VLAN 48 9600
One VLAN 48 9600
Two VLAN 48 9600
Ethernet/IPv4/UDP No VLAN 52 9600
One VLAN 56 9600
Two VLAN 60 9600
Ethernet/IPv6/UDP No VLAN 72 9600
One VLAN 76 9600
Two VLAN 80 9600
