EXFO AXS-200/850 Ethernet Test Set User Manual
Page 26
Using the Smart User Interface
16
AXS-200/850
Home Menu
6. Tools: Allows to ping, trace
route,cable test, and report.
1. Ping: Displays
tabs to configure
ping and to view
results and statistics.
Configuration
Results
Statistics
2. Trace Route:
Displays tabs to
configure trace
route and view
results.
Configuration
Results
3. Cable Test:
Displays tabs to
configure cable test
and view results.
Configuration
Results
4. Report: Allows to
configure and save
reports.
Configuration
b
File
Home Menu
Submenu
Tabs/Pages
