Traffic Generation & Monitoring
168 AXS-200/850
Sequence Results
The Alarm LEDs are described as follows:
Statistics for Total Frame Count
³
RX: Displays the total number of frames that are received.
³
TX: Displays the total number of frames that are transmitted.
LED Label Color Meaning
Out-of-Sequence Green No out-of-sequence declared.
Red Out-of-sequence declared in the last
second.
Amber Out-of-sequence was declared
(History).
Black Not applicable.
