Using the Smart User Interface
14 AXS-200/850
Home Menu
2. RFC 2544: Allows to
configure the subtests and to
view test results.
1. Configuration:
Displays tabs to
configure the global
and stream settings
and the subtest
settings.
Global
Stream
Throughput
Back-to-Back
Frame Loss
Latency
2. Results: Displays
tabs to view results
and alarms/errors.
Summary
Throughput
Back-to-Back
Frame Loss
Latency
Graph
Alarms/Errors
3. BERT: Allows Ethernet
traffic generation and analysis
up to Layer 4 with specific
test pattern for Bit Error Rate
analysis.
1. Configuration:
Displays tabs to
configure the global
and stream settings.
Global
Stream
2. Results: Displays
tabs to view results
and alarms/errors.
Summary
Detailed
Service Disruption
Alarms/Errors
3. Logger: Displays
the list of recorded
events.
Home Menu Submenu Tabs/Pages
