Fieldware-SA for the Legacy 6000
Software Version 2.00
Chapter 4 - Real-time Operation 4-3
Product Application
Real-time Pages
There are two real-time page types; the Rates page (Figure 4-2) and the Map page (Figure 4-5).
Each page has the same layout; a left column of soft-keys, a center column that displays rate or
map information, and a right column of soft-keys.
The left column is reserved for product control soft-keys. There is a soft-key for each product used
in the current product application. If there is only one product, there is no soft-key in the left col-
umn. E.G. if a Legacy 6000 is connected to an external rate controller configured as a two product
system there are two product control soft-keys. If there are more than four products being applied,
the left column becomes scroll-able to access the additional product control soft-keys. The left col-
umn is the same for the Rates page and the Map page. This allows the control of a product while
viewing the application map. A product control soft-key contains the product name and the current
rate being applied.
The right column soft-keys vary depending on which page is currently being viewed. When viewing
the map page, the right column contains all of the mapping, guidance, and general viewing soft-
keys. See Table 4-1 for a description of each soft-key. When viewing the Rates page, the right col-
umn contains various utility soft-keys such as an Alternative Rates page soft-key and the Alarm Off
soft-key.
