4-8 Chapter 4 - Real-time Operation
Product Application
Fieldware-SA for the Legacy 6000
Software Version 2.00
The Center Vehicle soft-key. Press this to center the vehicle in the map page.
The Apply Off soft-key. Indicates the current application status is OFF. When
this soft-key is pressed the vehicle trajectory is drawn behind the vehicle on the
map page. This soft-key changes to the Apply On soft-key.
The Apply On soft-key. Indicates the current application status is ON. When
this soft-key is pressed drawing of the vehicle trajectory behind the vehicle in
the map page is stopped. This soft-key changes to the Apply Off soft-key.
The Mark A soft-key, used with the Parallel pattern. This soft-key is pressed to
mark the first end point of the initial guideline. When pressed, this soft-key
changes to the Mark B soft-key.
The Mark B soft-key, used with the Parallel and Headland patterns. This soft-
key is pressed to mark the end point of the initial guideline. When pressed, this
soft-key changes to the New Guideline soft-key.
The New GuideLine soft-key. This soft-key appears after the initial guideline
has been created. When pressed, this soft-key changes to the Mark A soft-key
and guidance is disabled until a new guideline is created by pressing Mark A
and then Mark B.
The Switch Guideline soft-key. This soft-key appears when more than one
guideline has been created.
The Straight-line Parallel Guidance soft-key. This soft-key indicates the cur-
rent guidance pattern is straight-line parallel guidance. The initial guideline is
defined by marking end points A and B. Pressing this soft-key pops-up a side
menu that allows a different guidance mode, such as Headland or Circle Pivot,
to be selected.
The Curved-line Parallel Guidance soft-key. This soft-key indicates the cur-
rent guidance pattern is Curved guidance, used in the Headland pattern only.
Pressing this soft-key pops-up a side menu that allows a different guidance
mode, such as Straight-line or Circle Pivot, to be selected.
The Circle Pivot Parallel Guidance soft-key. This soft-key indicates the cur-
rent guidance pattern is Circle Pivot parallel guidance. The initial guideline is
defined by marking points A and B along a circle. Pressing this soft-key pops-
up a side menu that allows a different guidance mode, such as Headland or
Straight-line, to be selected.
The Circle Mark A soft-key, used with the Circle Pivot pattern. This soft-key is
pressed to mark the first end point of the initial circle guideline. When pressed
this soft-key changes to the Circle Mark B soft-key.
Soft-key Description
Table 4-1: Real time Soft-key Description
