2-26

Chapter 2 - Getting Started
System Setup

Fieldware-SA for the Legacy 6000

Software Version 2.00

Entering the Implement Width

See “Entering the Implement Width” on page 2-21.

Entering the Number of Sections in a Swath

The Sections page is where the number of sections in the swath is entered. The maximum number
of sections is nine. When the correct number of sections is entered, press the Forward Arrow but-
ton to move to the next setup page.

Swath sections are ordered left to right with respect to a forward facing vehicle. The left most section
is assigned number 1 and section numbers increase moving to the right across the swath (Figure 2-
12).

Figure 2-19: The Number of Sections
