5-10 Chapter 5 - Fieldware FieldPilot
Fieldware-SA Real-Time Operation
Fieldware-SA for the Legacy 6000
Software Version 2.00
Fieldware-SA Real-Time Operation
When the setup process is completed, real-time operation of FieldPilot and Fieldware can begin.
To start real-time setup and operation, press the Bull’s Eye button located on the Fieldware
Launcher page (Figure 5-8).
Real-time Setup
It is recommended that vehicle trajectory data be collected and stored to the PC card. Job reports
can be created in Mid-Tech’s Map Manager desktop software. Storing data also allows the AB
guideline file to be saved and used again at a later date. To collect data, make sure the PC Card
setting is set to Yes. This setting is located in Console setup (see “Console Setup” on page 2-13).
If data is being collected and stored, a new Job name must be entered or an existing job name
selected. This step takes place when the Main Launcher Bull’s Eye is pressed. When a Job name
has been entered, the Real-time setup menu is displayed (Figure 5-11). See Table 5-2 for a brief
description of the real-time setup components. For a more detailed description of real-time setup,
see “Fieldware - SA Real-Time Setup” on page 3-2.
Figure 5-11: The Real-time Setup Menu
