1-6 Chapter 1 - System Introduction
Legacy 6000 Console
Fieldware SA for the Legacy 6000
Software Version 2.00
Legacy 6000 Console
The Legacy 6000 console runs Fieldware - SA software and operates in a Windows CE environ-
ment; an extremely dependable and stable operating system. Operation is intuitive, with on-screen
menu choices and prompts. An on-board help menu is built in. The heart of the Legacy console is
an Intel processor operating at 206 Megahertz for maximum efficiency. Other features of the Leg-
acy 6000 console include:
Dimensions: 8.0" Wide x 7.7" High x 4.5" Deep (203 x 196 x 114 mm)
Weight: 2.3 lbs. (1.0 kg)
Enclosure: Sealed plastic; back lighted; tactile feed-back switches on front panel
Display: Color 5.7" diagonal (120 x 90 mm), transflective, QVGA with CCFL back lighting. Bright-
ness control via back light control over contrast using discreet switches.
Input/Output: CAN, Bosch 2.0B
Serial: RS 232 (2)
USB: (1)
TTL digital I/O: (10)
Memory: 64 Mbytes DRAM, 16Mbytes Flash
Microprocessor: 32-bit Intel StrongArm, SA 1110 with SA 1111 companion chip. 206 MHz.
Drives: PCMCIA type II, single slot
Operating System: Microsoft Windows CE 3.0
Power Requirement: 9 to 16 volts DC
Connector: Sealed, 31 pin Deutsch
GPS Receiver Compatibility: Compatible with any differentially corrected, submeter GPS
(DGPS) receiver that outputs NMEA 0183 at 2 to 5 Hz.
Alarm: Audible alarm
Other:
* Real-time clock with battery back-up
* Simple, yet versatile, RAM mounting bracket.
