2-12 Chapter 2 - Getting Started
System Setup
Fieldware-SA for the Legacy 6000
Software Version 2.00
Rate Control Mode
The Rate Controller mode implies that an external rate controller is connected to one of the COM
ports on the Legacy 6000 console. See “Compatible Rate Controllers” on page 2-32 for a list of
compatible rate controllers. In Rate Control mode there are several options to choose from. Appli-
cation Rate data can be collected, with or with out guidance. If rate data is being collected without
guidance, the option of using a lightbar or not is available. All data collected in Rate Control mode
is considered As-Applied data.
The Multi-product software activation is required for rate control of two or more products, see Table
2-1.
To setup in Rate Controller mode, the Controller setting in Controller setup must be set to the type
of rate controller connected to the Legacy 6000 console. If this setting is set to None, it is not pos-
sible to perform product application. Table 2-4 lists all of the different Rate Control mode options.
Log Data Mode without Lightbar
Lightbar Off If the Lightbar is set to Off, guidance can not be used, but Where-
Applied data can be logged to the PC card. The lightbar is not
required.
Setup
Name
Setting Description
Controller A Driver
Name In Controller setup, a controller driver name must be selected to pre-
form product application. See “Controller Setup” on page 2-31.
Rate Control with Guidance
Lightbar Text/Lights If the Lightbar setting is set to Text/Lights it is possible to use machine
guidance and log data to the PC card. See “Lightbar Setup” on page
2-15 for more information.
Log Data mode with a Lightbar and without Guidance
Lightbar Text-only If the Lightbar setting is set to Text-Only, it is not possible to use guid-
ance, but As-Applied data can be logged to the PC card.
Log Data mode without a Lightbar or Guidance
Lightbar Off If the Lightbar setting is set to Off, it is not possible to use guidance,
but As-Applied data can be logged to the PC card. The lightbar is not
required.
Table 2-4: Rate Control Mode Setting Options
Setup
Name
Setting Description
Table 2-3: Log Data and Guidance Only Mode Settings
