Page 59: 4device control (dctrl)
Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05
59
4
Device control (DCTRL)
4.2
Device states
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
4.2.6
OperationEnabled
In the "OperationEnabled" state
• is the controller if the controller inhibit is deactivated and no trouble ("Trouble") and fault
("Fault") are existent.
• the operation is enabled and the motor follows the setpoint defined by the active application
(in case of sensorless vector control only after the magnetisation process is completed).
Depending on certain conditions, a state change takes place based on the "OperationEnabled" de-
vice state.
Related topics:
Process data assignment for control via CAN
LED DRIVE READY
LED DRIVE ERROR
Display in status word 1 (
Bit 11
Bit 10
Bit 9
Bit 8
OFF
OperationEnabled
0
1
0
1
Change condition
Changeover to the device state
Control bit "EnableOperation" in control word wCANControl = "0"
OR terminal RFR = LOW level (controller inhibit).
Control bit "SwitchOn" = "0".
Undervoltage in the DC bus.
)
Error with error response "Trouble" occurs.
