10 Parameter reference
10.2 Parameter list | C00701
289
Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00701
C00725
Parameter | Name:
C00701 | LA_NCtrl: digital connection list
Data type: UNSIGNED_16
Index: 23874
d
= 5D42
h
Connection parameters for "Actuating drive speed" application: Binary inputs
• Selection of the binary output signals for connection with the binary input signals
• The selection list contains all binary output signals which can be assigned to the binary inputs mapped by the
subcodes.
Selection list
See
selection list - digital signals
Subcodes Lenze setting Info
C00701/1 0: Not connected LA_NCtrl : bCInh
C00701/2 15: DigIn_CInh LA_NCtrl : bFailReset
C00701/3 0: Not connected LA_NCtrl : bSetQuickstop
C00701/4 13: DigIn_bIn3 LA_NCtrl : bSetDCBrake
C00701/5 14: DigIn_bIn4 LA_NCtrl : bSetSpeedCcw
C00701/6 11: DigIn_bIn1 LA_NCtrl : bJogSpeed1
C00701/7 12: DigIn_bIn2 LA_NCtrl : bJogSpeed2
C00701/8 0: Not connected LA_NCtrl : bMPotUp
C00701/9 0: Not connected LA_NCtrl : bMPotDown
C00701/10 0: Not connected LA_NCtrl : bMPotInAct
C00701/11 0: Not connected LA_NCtrl : bMPotEnable
C00701/12 0: Not connected LA_NCtrl : bRFG_0
C00701/13 0: Not connected LA_NCtrl : bSetError1
C00701/14 0: Not connected LA_NCtrl : bSetError2
C00701/15 1: C_bTrue LA_NCtrl : bPIDInfluenceRamp
C00701/16 0: Not connected LA_NCtrl : bPIDIOff
C00701/17 1: C_bTrue LA_NCtrl : bRLQCw
C00701/18 0: Not connected LA_NCtrl : bRLQCcw
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00725 | Current switching frequency
Data type: UNSIGNED_8
Index: 23850
d
= 5D2A
h
Display of the current switching frequency
• When a variable switching frequency is selected in C00018 , the switching frequency may change as a function
of the load and rotational frequency.
Selection list
(read only)
1 4 kHz var./drive-optimised
2 8 kHz var./drive-optimised
3 16 kHz var./drive-optimised
5 2 kHz constant/drive-optimised
6 4 kHz constant/drive-optimised
7 8 kHz constant/drive-optimised
8 16 kHz constant/drive-optimised
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
