2 Introduction: Parameterising the controller
2.1 General notes on parameters
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
2.1 General notes on parameters
All parameters for controller parameterising or monitoring are saved as so-called "codes".
• The codes are numbered and designated by a "C" in front of the code, e.g. "C002" in the docu-
mentation and the keypad display.
• In addition, every code has a name and specific attributes:
• Access type (read, write)
• Data type
• Limit values
• Lenze setting (factory-set scaling)
• For the sake of clarity, some codes contain "subcodes" for saving parameters.
• This manual uses a slash "/" as a separator between code and subcode (e.g. "C115/1").
• In the keypad display, the subcodes are designated by a small "c", e.g. "c001".
• According to their functionality, the parameters are divided into three groups:

Tip!
The terms "code" and "subcode" generally correspond to the terms "index" and "subindex"
and "parameter" and "subparameter".
Parameter group Examples
Setting parameters
Parameters for specifying setpoints and for setting device /
monitoring functions.
C007 : Selection of control mode
C012 : Acceleration time - main setpoint
C039 : Fixed setpoints
Configuration parameters
Parameters for configuring signal connections within the de-
vice, e.g. assignment of the digital input terminals to the
control inputs of the application.
C620 : System connection list: 16-bit
C621 : System connection list: Bool
C700 : LA_NCtrl: Analog connection list
C701 : LA_NCtrl: Digital connection list
Diagnostic/Display parameters
Parameters for displaying device-internal process factors,
current actual values, and status messages, e.g. for diag-
nostic purposes. These are read-only parameters.
C052 : Motor voltage
C137 : Device status
C150 : Status word
C165 : Error info
