Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05
292
10 Parameter reference
10.2 Parameter list | C00806
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00806
C00830
C00831
Parameter | Name:
C00806 | L_MPot_1: Use
Data type: UNSIGNED_8
Index: 23769
d
= 5CD9
h
FB L_MPot_1 : Use of the motor potentiometer
Selection list (Lenze setting printed in bold) Info
0 No The motor potentiometer is not used.
• The analog value applied to the nIn_a input is looped
through without any changes to the nOut_a output.
1 Yes The motor potentiometer is used.
• The analog value applied at the nIn_a input is led via
the motor potentiometer and provided at the nOut_a
output.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00830 | 16-bit analogue input
Data type: INTEGER_16
Index: 23745
d
= 5CC1
h
Display in percent of 16-bit input values of different blocks
Display range
(min. value | unit | max. value)
-199.9 % 199.9
Subcodes Info
C00830/1 L_NSet_1 : nNSet_a
C00830/2 L_NSet_1 : nOut_a
C00830/3 LS_MCTRL: nSpeedSetValue_a
C00830/4 LS_MCTRL: nTorqueMotLimit_a
C00830/5 LS_MCTRL: nTorqueGenLimit_a
C00830/6 L_PCTRL_1 : nAct_a
C00830/7 L_PCTRL_1 : nAdapt_a
C00830/8 L_PCTRL_1 : nSet_a
C00830/9 L_PCTRL_1 : nInflu_a
C00830/10 L_PCTRL_1 : nNSet_a
C00830/11 L_MPot_1 : nIn_a
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00831 | 16-bit common input
Data type: UNSIGNED_16
Index: 23744
d
= 5CC0
h
Decimal/hexadecimal/bit-coded display of 16-bit input values of different blocks
Display area
(min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded:
Bit 0 Bit0
... ...
Bit 15 Bit15
Subcodes Info
C00831/1 LS_DCTRL : wCANControl
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
