10 Parameter reference
10.2 Parameter list | C00347
269
Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00347
C00350
C00351
Parameter | Name:
C00347 | CAN status HeartBeat producer
Data type: UNSIGNED_8
Index: 24228
d
= 5EA4
h
 System bus "CAN on board": Heartbeat protocol
Selection list (read only)
0 Boot-up
4 Stopped
5 Operational
127 Pre-Operational
250 Failed
255 NoResponse
Subcodes Info
C00347/1 Status node 1
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00350 | CAN node address
Data type: UNSIGNED_8
Index: 24225
d
= 5EA1
h
Setting of the node address via parameters
• The node address can only be parameterised if the node address "0" is set via the DIP switches.
• A change of the node address will only become effective after a CAN reset node.
 System bus "CAN on board"
Setting range (min. value | unit | max. value) Lenze setting
1 63 1
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00351 | CAN baud rate
Data type: UNSIGNED_8
Index: 24224
d
= 5EA0
h
Setting of the baud rate via parameters
• The baud rate can only be parameterised if the baud rate "0" is set via the DIP switches.
• A change of the baud rate will only become effective after a CAN reset node.
 System bus "CAN on board"
Selection list (Lenze setting printed in bold)
0 500 kbps
1 250 kbps
2 125 kbps
3 50 kbps
4 1000 kbps
5 20 kbps
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
