7.5 Terminal assignment of the control modes
The following table shows which functions are assigned to the digital terminals in the different control modes.
Related topics:
 User-defined terminal assignment ( 114)
 Pre-assignment of the drive application ( 133)
Analog input Assignment of the digital terminals Relay output
Control mode A1U DI1 DI2 DI3 DI4 DO1 NO / COM
Terminals 0 Setpoint selection
10 V ≡ 100 % refe-
rence speed ( C011 )
JOG 1/3 JOG 2/3 DCB Cw/Ccw Status
"Drive is ready to
start"
Status
"An error occurred"
Terminals 2 JOG 1/3 JOG 2/3 QSP Cw/Ccw
Terminals 11 Cw/Ccw DCB MPotUp MPotDown
Terminals 16 JOG 1/3 JOG 2/3 Cw/QSP Ccw/QSP
Keypad - - - - -
PC - - - - -
CAN - QSP - - -
Abbreviations used:
JOG Selection of the fixed setpoints 1 ... 3 in C039/1...3
DCB Manual DC-injection braking
Cw/Ccw CW/CCW rotation
QSP Quick stop
MPotUp Motor potentiometer: Increase speed
MPotDown Motor potentiometer: Decrease speed
Cw/QSP Fail-safe selection of the direction of rotation in connection with quick stop
Ccw/QSP
