3 Commissioning
3.5 PC manual control
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
3.5 PC manual control
This function extension is available as of version 03.03.00 and is supported by the »Engineer« as of
version 2.14!
For test and demonstration purposes, PC manual control can be used to manually control various
drive functions via the »Engineer« when an online connection has been established.
Supported drive functions:
• Speed control (follow a speed setpoint)
• Activate/Deactivate quick stop
More control functions:
• Reset of error message
•
Set digital/analog outputs (in preparation)
Diagnostic functions:
• Display of the actual speed value and motor current (in a temporal characteristic)
• Display of the current device state
• Display of the status determining error
•
Display of the status of the digital/analog inputs (in preparation)
3.5.1 Activating PC manual control

Stop!
PC manual control must be explicitly activated by the user.
If PC manual control is activated, the controller is inhibited via device command (
C002/
16 ) first.

Note!
For activated PC manual control:
The online connection between the PC and the controller is monitored by the controller.
• If the online connection is interrupted for longer than 2 s, error response "Fault" is trig-
gered, i.e. the motor becomes torqueless and is coasting unless it already is at stand-
still.
PC manual control transmits all required control and setpoint signals to the motor inter-
face.
• The application is now decoupled from these interfaces, but will be processed as be-
fore and remains unchanged.
• It does not matter what type of motor control is set in C006 .
