Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05
288
10 Parameter reference
10.2 Parameter list | C00700
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00700
Parameter | Name:
C00700 | LA_NCtrl: Analog connection list
Data type: UNSIGNED_16
Index: 23875
d
= 5D43
h
Connection parameters for "Actuating drive speed" application: 16-bit inputs
• Selection of the 16-bit output signals for connection with the 16-bit input signals
• The selection list contains all 16-bit output signals which can be assigned to the 16-bit inputs mapped by the
subcodes.
Selection list
See
selection list - analog signals
Subcodes Lenze setting Info
C00700/1 10: AIn1_Out LA_NCtrl : nMainSetValue_a
C00700/2 22: nPar3_a LA_NCtrl : nTorqueMotLim_a
C00700/3 22: nPar3_a LA_NCtrl : nTorqueGenLim_a
C00700/4 0: Not connected Reserved
C00700/5 6: C_wDriveCtrl LA_NCtrl : wCANDriveControl
C00700/6 1: C_nPos100_a(100.0%) LA_NCtrl : nPIDVpAdapt_a
C00700/7 0: Not connected LA_NCtrl : nPIDActValue_a
C00700/8 1: C_nPos100_a(100.0%) LA_NCtrl : nPIDInfluence_a
C00700/9 0: Not connected LA_NCtrl : nPIDsetValue_a
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
