2.3.5 User menu
The user menu (menu -0-) contains a selection of frequently used parameters to be able to access
and change these parameters quickly.
• The integrated keypad serves to change the preset parameter selection in C517 : Enter the codes
the user menu is to contain into the subcodes c001 ...c020. When "0" is set, no entry is displayed
in the user menu.
• The »Engineer« serves to configure the user menu on the User menu tab of the controller. Here,
additional functions are available for loading and saving the parameter selection.
The user menu contains the following parameters:
Code Subcode Info Lenze setting
Value Unit
C051 - Display of actual speed value - rpm
C053 - Display of DC-bus voltage - V
C054 - Display of motor current - A
C061 - Display of heatsink temperature - °C
C137 - Display of device status -
C011 - Reference speed 1500 rpm
C039 c001 Fixed setpoint 1 40.0 %
c002 Fixed setpoint 2 60.0 %
c003 Fixed setpoint 3 80.0 %
C012 - Acceleration time - main setpoint 2.0 s
C013 - Deceleration time - main setpoint 2.0 s
C015 - V/f base frequency 50.0 Hz
C016 - Vmin boost 0.0 %
C022 - Imax in motor mode 47.00 A
C120 - Motor overload threshold (I 2 xt) 100 %
C087 - Rated motor speed 1460 rpm
C099 - Display of firmware version -
Highlighted in grey = display parameter

Note!
If the password protection is activated and no password or a wrong password is entered,
only these parameters can be accessed with the integrated keypad.
 Password protection ( 23)
