Lenze 8400 BaseLine C - Manual (Page 279)

10 Parameter reference
10.2 Parameter list | C00472
279
Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00472
C00480
C00481
Parameter | Name:
C00472 | LS_ParFree_a
Data type: INTEGER_16
Index: 24103
d
= 5E27
h
SB LS_ParFree_a : Setting of the analog signals to be output
Setting range (min. value | unit | max. value)
-199.9 % 199.9
Subcodes Lenze setting Info
C00472/1 0.0 % Value for output nPar1_a
C00472/2 0.0 % Value for output nPar2_a
C00472/3 100.0 % Value for output nPar3_a
C00472/4 100.0 % Value for output nPar4_a
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00480 | LS_DisFree_b
Data type: UNSIGNED_8
Index: 24095
d
= 5E1F
h
SB LS_DisFree_b : Display of the input values
Display area (min. hex value | max. hex value)
0x00 0xFF
Value is bit-coded: Info
Bit 0 bDis1 Signal level input bDis1 ... bDis8
... ...
Bit 7 bDis8
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00481 | LS_DisFree
Data type: UNSIGNED_16
Index: 24094
d
= 5E1E
h
SB LS_DisFree : Display of the input values
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded:
Bit 0 Bit0
... ...
Bit 15 Bit15
Subcodes Info
C00481/1 Input values wDis1 ... wDis4
C00481/...
C00481/4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
