11.3 L_PCTRL_1
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
11.3.1 Control characteristic
The PI algorithm is active in the Lenze setting.
Gain (P component)
The input value is controlled by a linear characteristic. The slope of the characteristic is determined
by the controller gain Vp.
The controller gain Vp is set under
C222 .
• The controller gain can be adapted via the input nAdapt_a (also possible in online mode).
• The input value nAdapt_a has a direct effect on the controller gain:
Example: With the parameterised controller gain Vp = 2.0 and nAdapt_a = 75 %, the resulting gain
factor is as follows:
Integral action component (I component)
The I component of the controller can be deactivated by setting the input bIOff to TRUE.
• Setting the reset time Tn to the maximum value of "6000 ms" also deactivates the I component.
• The I component can be switched on and off online.
Adjustment time
The reset time Tn is set under
C223 .
Differential component Kd (D component)
The differential component Kd is set under
C224 .
• The setting "0.0" deactivates the D component (Lenze setting). In this way, the PID controller be-
comes a PI controller or P controller, if the I component has been deactivated as well.
P nAdapt_a C00222 ⋅ =
P
75 [%]
100 [%]
------------------- 2.0 ⋅ 1.5 = =
