Lenze 8400 BaseLine C - Manual (Page 268)

Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05
268
10 Parameter reference
10.2 Parameter list | C00324
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00324
C00345
Parameter | Name:
C00324 | CAN transmit blocking time
Data type: UNSIGNED_16
Index: 24251
d
= 5EBB
h
As of version 03.03.00
Blocking time for transmitting the emergency telegram and the process data
Note:
If the "asynchronous - manufacturer-specific/device-profile specific" transmission type has been set, the transmis-
sion cycle timer is reset to 0 if transmission has been triggered in an event-controlled manner.
Example: Cycle time ( C00356/x ) = 500 ms, blocking time = 100 ms, sporadic data change:
• In case of a sporadic data change < 500 ms, fastest transmission is every 100 ms due to the set blocking time
(event-controlled transmission).
• In case of a sporadic data change > 500 ms, fastest transmission is every 500 ms due to the set blocking time (cy-
clic transmission).
 System bus "CAN on board"
Setting range (min. value | unit | max. value)
0 ms 6500
Subcodes Lenze setting Info
C00324/1 0 ms Emergency blocking time
C00324/2 0 ms CAN1_OUT blocking time
C00324/3 0 ms CAN2_OUT blocking time
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00345 | CAN error status
Data type: UNSIGNED_8
Index: 24230
d
= 5EA6
h
 System bus "CAN on board"
Selection list (read only)
0 No Error
1 Warning ErrActive
2 Warning ErrPassive
3 Bus off
4 Reserved
5 Reserved
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
