10 Parameter reference
10.2 Parameter list | C00228
265
Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00228
C00231
C00234
C00235
C00236
Parameter | Name:
C00228 | L_PCTRL_1: Deceleration time
Data type: UNSIGNED_32
Index: 24347
d
= 5F1B
h
FB L_PCTRL_1 : Deceleration time for the output value of the PID process controller
Setting range (min. value | unit | max. value) Lenze setting
0.0 s 999.9 0.1 s
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
Parameter | Name:
C00231 | L_PCTRL_1: Operating range
Data type: INTEGER_16
Index: 24344
d
= 5F18
h
FB L_PCTRL_1 : Operating range for the PID process controller
Setting range (min. value | unit | max. value)
0.0 % 199.9
Subcodes Lenze setting Info
C00231/1 199.9 % L_PCTRL_1 : Pos. maximum
C00231/2 0.0 % L_PCTRL_1 : Pos. minimum
C00231/3 0.0 % L_PCTRL_1 : Neg. minimum
C00231/4 199.9 % L_PCTRL_1 : Neg. maximum
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00234 | Oscillation damping influence
Data type: UNSIGNED_16
Index: 24341
d
= 5F15
h
 Oscillation damping
Setting range (min. value | unit | max. value) Lenze setting
0 % 250 5 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00235 | Filter time - oscill. damping
Data type: UNSIGNED_8
Index: 24340
d
= 5F14
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00236 | Oscillation damping - field weakening
Data type: UNSIGNED_8
Index: 24339
d
= 5F13
h
This code is for device-internal use only and must not be written to by the user!
