10 Parameter reference
10.2 Parameter list | C00024
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00024
C00026
C00027
C00028
Parameter | Name:
C00024 | Comparison value N_Act
Data type: INTEGER_16
Index: 24551
d
= 5FE7
h
Threshold for the actual speed comparison
• This parameter serves to set a threshold that is compared with the actual speed value.
• When the value falls below this threshold, the bNactCompare output of the SB LS_DriveInterface switches to
TRUE.
• Switching hysteresis = +1 %
Setting range (min. value | unit | max. value) Lenze setting
0.0 % 199.9 0.0 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00026 | AINx: Offset
Data type: INTEGER_16
Index: 24549
d
= 5FE5
h
Offset for analog input
 Analog terminals
Setting range (min. value | unit | max. value)
-199.9 % 199.9
Subcodes Lenze setting Info
C00026/1 0.0 % AIN1: Offset
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00027 | AINx: Gain
Data type: INTEGER_32
Index: 24548
d
= 5FE4
h
Gain for analog input
 Analog terminals
Setting range (min. value | unit | max. value)
-199.9 % 199.9
Subcodes Lenze setting Info
C00027/1 100.0 % AIN1: Gain
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00028 | AINx: Input voltage
Data type: INTEGER_16
Index: 24547
d
= 5FE3
h
Display of the input voltage at the analog input
 Analog terminals
Display range
(min. value | unit | max. value)
-10.0 V 10.0
Subcodes Info
C00028/1 AIN1: Input voltage
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
