11 Function library
11.10 LS_DisFree_b
324
Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
11.10 LS_DisFree_b
This system block displays any eight digital signals of the application on a bit-coded display code.
The signals to be displayed are selected via the given configuration parameters.
Inputs
Parameter
Identifier
Data type
Information/possible settings
bDis1 ... bDis8
BOOL
Inputs for any digital signal of the application
Parameter Possible settings Info
C480 0x0000 0xFFFF Display of the digital signals applied
at the bDis1 ... bDis8 inputs in the
form of hexadecimal values
Bit 0 Signal level at the bDis1 input
Bit 1 Signal level at the bDis2 input
Bit 2 Signal level at the bDis3 input
... ...
Bit 7 Signal level at the bDis8 input
C621/16...23 See selection list - digital signals Configuration parameters for the in-
puts bDis1 ... bDis8
E'LV
E'LV
E'LV
E'LV
E'LV
&
%LW
%LW
%LW
%LW
%LW
/6B'LV)UHHBE
&
&
&RQILJXUDWLRQSDUDPHWHUV
&
&
E'LV
E'LV
E'LV
&
&
&
&
%LW
%LW
%LW
