10 Parameter reference
10.2 Parameter list | C00242
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00242
C00243
C00244
C00245
C00308
Parameter | Name:
C00242 | L_PCTRL_1: Operating mode
Data type: UNSIGNED_8
Index: 24333
d
= 5F0D
h
FB L_PCTRL_1 : Selection of the operating mode
• Depending on the selection, the blue switches in the displayed signal flow are set accordingly in the Engineer on
the Application parameter tab in the Overview  Signal flow  Process controller dialog level.
Selection list (Lenze setting printed in bold) Info
0 Off The input setpoint nNSet_a is output without any chan-
ges at the output nOut_a.
1 Additive + feedforward control nNSet_a and nAct_a are used as PID input values. The ar-
riving nNSet_a is additively linked to the value output by
the PID element.
2 PID as setpoint generator. nSet_a and nAct_a are used as PID input values. The in-
put nNSet_a is not considered.
3 PID setpoint from L_NSet_1 nNSet_a and nAct_a are used as PID input values. The in-
put nSet_a is not considered.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00243 | L_PCTRL_1: Acceleration time influence
Data type: UNSIGNED_32
Index: 24332
d
= 5F0C
h
FB L_PCTRL_1 : Acceleration time for showing the PID output value
Setting range (min. value | unit | max. value) Lenze setting
0.0 s 999.9 5.0 s
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
Parameter | Name:
C00244 | L_PCTRL_1: Deceleration time influence
Data type: UNSIGNED_32
Index: 24331
d
= 5F0B
h
FB L_PCTRL_1 : Deceleration time for masking out the PID output value
Setting range (min. value | unit | max. value) Lenze setting
0.0 s 999.9 5.0 s
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
Parameter | Name:
C00245 | L_PCTRL_1: PID output value
Data type: INTEGER_16
Index: 24330
d
= 5F0A
h
FB L_PCTRL_1 : Display of the output value of the PID process controller
Display range (min. value | unit | max. value)
-199.9 % 199.9
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00308 | Activation of internal features
Data type: UNSIGNED_16
Index: 24267
d
= 5ECB
h
This code is for device-internal use only and must not be written to by the user!
