Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05
175
9 System bus "CAN on board"
9.3 Going online via system bus (CAN on board)
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
9.3 Going online via system bus (CAN on board)
The integrated system bus interface (CAN on board, X1 terminal) can also be used for the commu-
nication between the »Engineer« and the controller, alternatively to the USB diagnostic adapter.
• Lenze offers the following communication accessories for connection to the PC:
Communication accessories PC interface
PC system bus adapter 2173
incl. connection cable and voltage supply adapter
• for DIN keyboard connection (EMF2173IB)
• for PS/2 keyboard connection (EMF2173IBV002)
• for PS/2 keyboard connection with electrical isolation (EMF2173IBV003)
Parallel interface
(LPT port)
PC system bus adapter 2177
incl. connection cable (EMF2177IB)
USB
(Universal Serial Bus)

Note!
• For detailed information about the PC system bus adapter, please see the "CAN Com-
munication Manual".
• Please observe the documentation for the PC system bus adapter!
• In the »Engineer«, go to the Device assignment offline devices dialog box and select the
"System bus CAN" entry from the Bus connection list field to establish an online con-
nection.
