V/f characteristic control (VFCplus) 78
Motor control (C00006) 237
Motor cosine phi (C00091) 249
Motor current (C00054) 245
Motor data 65
Motor load monitoring (I2xt) 104
Motor magnetising current (C00095) 250
Motor magnetising inductance (C00092) 249
Motor overload threshold (I²xt) (C00120) 253
Motor parameter identification 70
Motor parameter identification is active 56
Motor selection 65
Motor stator leakage inductance (C00085) 248
Motor stator resistance (C00084) 247
Motor voltage (C00052) 245
N
Network management telegram (NMT) 181
NMT (network management) 181
Node address 176
Node ID 176
Number of CAN SDO channels (C00366) 273
O
OC1
Power section - short circuit (error message) 162
OC12
I2xt overload - brake resistor (error message) 163
OC2
Power section - earth fault (error message) 163
OC5
Ixt overload (error message) 161
OC6
I2xt overload - motor (error message) 163
OC9
Ixt overload - shutdown limit (error message) 162
OH
Heatsink overtemperature (error message) 161
Operating conditions (CAN on board) 171
Oscillation damping 100
Oscillation damping influence (C00234) 265
OU
DC bus overvoltage (error message) 162
Output frequency (C00058) 246
P
Password (C00094) 249
Password protection 23
PC manual control 39
PDO mapping 185
,
186
PDO synchronisation 192
PDO valid / invalid (C00389) 275
Peak current limitation 76
Plant parameters 69
Port block "LP_CanIn1" 185
Port block "LP_CanIn2" 186
Port block "LP_CanOut1" 187
Port block "LP_CanOut2" 188
Power section identification (C00093) 249
Power-on time meter (C00179) 262
Pre-defined error field (I-1003) 214
Process data objects, identifiers 189
Processing time 172
Producer heartbeat time (I-1017) 217
Product type code (C00203) 263
PS01
No memory module (error message) 165
PS02
Par. set invalid (error message) 165
PS03
Par. set device invalid (error message) 166
PS04
Par. set device incompatible (error message) 166
PS31
Ident. error (error message) 166
R
Ramp smoothing, main setpoint (C00134) 253
Rated motor current (C00088) 248
Rated motor frequency (C00089) 248
Rated motor power (C00081) 247
Rated motor speed (C00087) 248
Rated motor torque (C00097) 250
Rated motor voltage (C00090) 249
Reduced brake chopper threshold (C00174) 262
Reset of error message 158
Resp. to brake resist. overtemp. (C00574) 282
Resp. to CAN bus connection (C00592) 282
Resp. to CANx_IN monitoring (C00593) 283
Resp. to control word error (C00594) 283
Resp. to DC bus undervoltage (C00600) 284
Resp. to device overload (Ixt) (C00604) 284
Resp. to LS_SetError_x (C00581) 282
Resp. to mains phase failure (C00565) 281
Resp. to motor overload (I²xt) (C00606) 284
Resp. to open circuit AINx (C00598) 283
RPDO1 communication parameter (I-1400) 221
RPDO1 mapping parameter (I-1600) 223
RPDO2 communication parameter (I-1401) 222
RPDO2 mapping parameter (I-1601) 223
S
Safety instructions 11
Save parameter settings 49
Saving parameters automatically 49
SDO1 server parameter (I-1200) 218
SDO2 server parameter (I-1201) 219
Selection help for motor control 75
