1 About this documentation
1.4 Definition of the notes used
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
1.4 Definition of the notes used
The following signal words and symbols are used in this documentation to indicate dangers and im-
portant information:
Safety instructions
Layout of the safety instructions:
Application notes
USB diagnostic adapter The USB diagnostic adapter is used for the operation, parameterisation, and di-
agnostics of the controller. Data are exchanged between the PC (USB connec-
tion) and the controller (diagnostic interface on the front) via the diagnostic
adapter.
• Order designation: E94AZCUS
VFCplus Motor control: V/f characteristic control ("Voltage Frequency Control")
Term Meaning

Pictograph and signal word!
(characterise the type and severity of danger)
Note
(describes the danger and informs how to prevent dangerous situations)
Pictograph Signal word Meaning
 Danger! Danger of personal injury through dangerous electrical voltage
Reference to an imminent danger that may result in death or serious personal injury
if the corresponding measures are not taken.
 Danger! Danger of personal injury through a general source of danger
Reference to an imminent danger that may result in death or serious personal injury
if the corresponding measures are not taken.
 Stop! Danger of property damage
Reference to a possible danger that may result in property damage if the correspon-
ding measures are not taken.
Pictograph Signal word Meaning
 Note! Important note to ensure trouble-free operation
 Tip! Useful tip for easy handling
