10
Parameter reference
10.2
Parameter list | C00010
239
Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00010
C00011
C00012
C00013
Parameter | Name:
C00010 | Minimum analog setpoint
Data type: INTEGER_16
Index: 24565
d
= 5FF5
h
As of version 03.00.00
Lower limit for analog input
Setting range
(min. value | unit | max. value)
0.0
%
100.0
Subcodes
Lenze setting
Info
C00010/1
0.0 %
Min. analog setpoint
Read access Write access CINH PLC STOP No transfer COM MOT
Scaling factor: 100
Parameter | Name:
C00011 | Appl.: Reference speed
Data type: UNSIGNED_16
Index: 24564
d
= 5FF4
h
Setting the reference speed
• In the controller, all speed-related signals are processed to one reference variable in percent.
• Set a reference speed here that corresponds to 100 %.
• The frequency of the set reference speed is displayed in
.
Note:
This is not a maximum limitation!
All values in percent in the controller may be in the range of 0 ... 199.99 %.
Setting range
(min. value | unit | max. value)
Lenze setting
50
rpm
9999 1500 rpm
Read access Write access CINH PLC STOP No transfer COM MOT
Scaling factor: 1
Parameter | Name:
C00012 | Acceleration time main setpoint
Data type: UNSIGNED_32
Index: 24563
d
= 5FF3
h
FB
: Acceleration time of the ramp generator for the main speed setpoint
Setting range
(min. value | unit | max. value)
Lenze setting
0.0
s
999.9 2.0 s
Read access Write access CINH PLC STOP No transfer COM MOT
Scaling factor: 1000
Parameter | Name:
C00013 | Deceleration time main setpoint
Data type: UNSIGNED_32
Index: 24562
d
= 5FF2
h
FB
: Deceleration time of the ramp generator for the main speed setpoint
Setting range
(min. value | unit | max. value)
Lenze setting
0.0
s
999.9 2.0 s
Read access Write access CINH PLC STOP No transfer COM MOT
Scaling factor: 1000
