L-force | PLC Designer - SoftMotion
The SM_Error.lib library
The enumeration SMC_Error
1003
SMC_Interpolator
SMC_INT_DATA_UNDERRUN Warning:
GEOINFO list processed in DataIn, but the
end of the list is not set. Reason:
Forgotten to set EndOfList for the queue
in DataIn or SMC_Interpolator is faster
then the program organisation units
generating the path
1004
SMC_Interpolator
SMC_INT_VEL_NONZERO_A
T_STOP
Velocity at stop position > 0
1005
SMC_Interpolator
SMC_INT_TOO_MANY_REC
URSIONS
Too many SMC_Interpolator recursions.
SoftMotion error
1006
SMC_Interpolator
SMC_INT_NO_CHECKVELOCI
TIES
Input OutQueue DataIn has not
processed the SMC_CHeckVelocities
program organisation unit last
1007
SMC_Interpolator
SMC_INT_PATH_EXCEEDED
Internal/numerical error
1008
SMC_Interpolator
SMC_INT_VEL_ACC_DEC_ZE
RO
Speed, acceleration or deceleration zero
or too small.
1050
SMC_Interpolator2Dir
SMC_INT2DIR_BUFFER_TOO
_SMALL
Data buffer too small
1051
SMC_Interpolator2Dir
SMC_INT2DIR_PATH_FITS_N
OT_IN_QUEUE
Path does not fit completely into the
queue
1080
SMC_Interpolator
SMC_WAR_INT_OUTQUEUE
_TOO_SMA
LL
Warning: OutQueue DataIn has been
inadequately dimensioned. Stops may
not be able to be performed.
1081
SMC_Interpolator
SMC_WAR_END_VELOCITIES
_INCORRECT
Warning: Inconsistent end velocities
1100
SMC_CheckVelocities
SMC_CV_ACC_DEC_VEL_NO
NPOSITIVE
Impermissible velocity, deceleration or
acceleration values
1200
SMC_NCDecoder
SMC_DEC_ACC_TOO_LITTLE Impermissible acceleration value
1201
SMC_NCDecoder
SMC_DEC_RET_TOO_LITTLE Impermissible acceleration value
1202
SMC_NCDecoder
SMC_DEC_OUTQUEUE_RAN
_EMPTY
Data underrun. Queue has been read and
is empty.
1300
SMC_GCodeViewer
SMC_GCV_BUFFER_TOO_SM
ALL
Buffer too small
1301
SMC_GCodeViewer
SMC_GCV_BUFFER_WRONG
_TYPE
Buffer elements are of the wrong type
1302
SMC_GCodeViewer
SMC_GCV_UNKNOWN_IPO_
LINE
Current line of the interpolator could not
be found
1500
All function POUs that use
SMC_CNC_REF
SMC_NO_CNC_REF_TYPE
Entered CNC program is not of type
SMC_CNC_REF
1501
All function POUs that use
SMC_OUTQUEUE
SMC_NO_OUTQUEUE_TYPE Entered OutQueue is not of type
SMC_OUTQUEUE
2000
SMC_ReadNCFile
SMC_RNCF_FILE_DOESNT_E
XIST
File does not exist
2001
SMC_ReadNCFile
SMC_RNCF_NO_BUFFER
No buffer created
2002
SMC_ReadNCFile
SMC_RNCF_BUFFER_TOO_S
MALL
Buffer too small
2003
SMC_ReadNCFile
SMC_RNCF_DATA_UNDERR
UN
Data underrun. Buffer has been read and
is empty.
2004
SMC_ReadNCFile
SMC_RNCF_VAR_COULDNT_
BE_REPLACED
Placeholder variable could not be
replaced
2005
SMC_ReadNCFile
SMC_RNCF_NOT_VARLIST
Input pvl is not pointing to an
SMC_VARLIST object
Error
POU
Enum value
Description
