L-force | plc designer - softmotion – Lenze PLC Designer PLC-Designer (R2-x) SoftMotion User Manual
Page 104

L-force | PLC Designer - SoftMotion
CAM editor
Cam data structures
104
L
DMS 5.2 EN 03/2011 TD17
byVarType:BYTE (only for byType=1 or byType=2)
Variable type of which the cam table is comprised:
1: INT
2: UINT
3: DINT
4: UDINT
5: REAL
6: LREAL
nElements:INT
Number of elements, according to type slave positions, master/slave positions or XYVA
points
byInterpolationQuality:BYTE (only for byType=1 or byType=2)
Fine interpolation degree: 1: linear (default), 3: cubic
pce: POINTER TO BYTE
Pointer to the actual data element; depending on type:
nTappets: INT
Number of tappet actions
pt: POINTER TO SMC_CAMTappet
Pointer to an ARRAY OF SMC_CAMTappet
strCAMName:STRING
Name of cam
Type
1 (equidistant)
SMC_CAMTable_
2 (non-equidistant)
SMC_CAMTable_
3 (XYVA)
ARRAY OF SMC_CAMXYVA
