4×analog output ±10V
The modular system
4.18
L
4.18−3
EDSPM−TXXX−9.0−11/2009
Type
4×analog output ±10V
Voltage supply
DC 5 V / 60 mA (via backplane bus)
External voltage supply
DC 24 V / 100 mA (DC 19.2 ... 28.8 V)
Connectable cable cross−section
£ 2.5 mm
2
(
³ AWG 14)
Analog outputs
Number
4 outputs
Analog−to−digital converter
12 Bit
Output range
Voltage
−10 ... +10 V
Information on tolerances can be
found in the chapter "Parameter
setting"
Actuator − input resistance
> 5 k
W
Output current
< 6 mA
Delay time per channel
450
ms
Electrical isolation from backplane bus
Yes, via optocouplers
Communication
Output data
8 bytes (2 bytes per analog output)
Dimensions
Width
25.4 mm
Height
76.0 mm
Depth
76.0 mm
Weight
100 g
Order number
EPM−T321
