General data/operating conditions
3
Technical data
3.1
L
3.1−1 EDSPM−TXXX−9.0−11/2009
3.1 General data/operating conditions
)
Note!
l The technical data of the modules of the modular system is
included in the chapter "The modular system" in the
corresponding module description.
l The technical data of the modules of the compact system is
included in the chapter "The compact system" in the
corresponding module description.
Conformity and approval
Conformity
CE 73/23/EEC Low−Voltage Directive
Approval
UL UL 508 Power Conversion Equipment
Protection of persons and device protection
Type of protection
IP20
Electrical isolation
Modular system, compact modules
To the fieldbus Via optocouplers
To the process level Via optocouplers
Insulation resistance IEC 61131−2
Insulation voltage to reference earth
Inputs / outputs AC/DC 50 V, test voltage AC 500 V
Protective measures Against short circuit
EMC
Noise emission
EN 61000−6−4
Noise immunity EN 61000−4−2 ESD
EN 61000−4−3 HF interference (enclosure)
EN 61000−4−4 Burst
Ambient conditions
Climatic
Storage IEC/EN 60068−2−14 −25 ... +70 °C
Operation
Horizontal installation EN 61131−2 0 ... +60 °C
Vertical installation 0 ... +40 °C
Air humidity 60068−2−30 RH1 (without condensation, relative humidity 10 ... 95 %)
Pollution EN EN 61131−2 Degree of pollution 2
Mechanical
Vibration resistance IEC 60068−2−6 1 g
IEC 60068−2−27 15 g
Mounting conditions
Mounting place
In the control cabinet
Mounting position Horizontal and vertical
Station design
Modular system 1 gateway module with up to 32 electronic modules attached to it
without any free space
General data
Operating conditions
