CAN GatewayECO
The modular system
4.2
L
4.2−4
EDSPM−TXXX−9.0−11/2009
Type
CAN GatewayECO
Voltage supply
Voltage
DC 24 V (DC 20.4 ... 28.8 V)
Max. current consumption CAN
GatewayECO
0.3A
Max. current consumption of electronic
modules
0.8A
Connectable cable cross−section
£ 2.5 mm
2
(
³ AWG 14)
Communication
Communication protocol
·
System bus (CAN)
·
CANopen (CAL−based communication profile DS301/DS401)
Communication medium
DIN ISO 11898
Network topology
Line (terminated at both ends)
Max. cable length
Baud rate [kbit/s]
10
20
50
100
125
250
500
800
1000
Cable length [m]
5000 2500 1000
600
500
250
80
50
25
Max. number of nodes
63
Electrical isolation from system bus
Yes, via optocouplers
Connectable electronic modules
Max. number of electronic modules
8
The number is limited by the maximum current
consumption of electronic modules.
Max. number of digital input/output
modules
8
Max. number of analog input/output
modules
8
Max. digital input data
8 bytes
Max. digital output data
8 bytes
Max. analog input data
64 bytes
Max. analog output data
64 bytes
Dimensions
Width
25.4 mm
Height
76.0 mm
Depth
76.0 mm
Weight
80 g
Order designation
EPM−T111
Technical data
