The compact system
Mechanical installation
6.2
L
6.2−1
EDSPM−TXXX−9.0−11/2009
6.2
The compact system
Mounting dimensions and other dimensions
34 mm
101 mm
48 mm
34
mm
27
mm
35
mm
76
mm
EPM-T830
34 mm
152 mm
76
mm
69
mm
34
mm
48 mm
EPM-T833
0
1
0
1
34 mm
101 mm
76
mm
69
mm
34
mm
48 mm
EPM-T831
0
1
34 mm
152 mm
76
mm
69
mm
34
mm
48 mm
EPM-T832
0
1
30 mm
7.5/15 mm
epm−t054
Fig. 6.2−1
Module dimensions of the compact system
