Parameterising analog modules
Signal functions of 4xanalog input ±10
13
Parameter setting via PROFIBUS−DP
13.1
13.1.5
L
13.1−11 EDSPM−TXXX−9.0−11/2009
13.1.5 Signal functions of 4xanalog input ±10
)
Note!
l Short−circuit unused inputs (connect positive and negative
terminals) or deactivate them by assigning the function number
FF
h
.
l In the event of an overflow or underflow, wrong values are
output. Strong signal jumps with sign reversal may occur.
I/O system IP20 multiplies measured values with decimal positions and without
normalisation by a factor and transfers them as integers to the bus. To output the
decimal positions, divide the measured values by the same factor.
Example:
Measuring task: Voltage measurement with signal function 28
h
. Measured value = 8.5 V.
1. I/O system IP20 converts the measured value into an integer:
8.5 [V] × 10 = 85
2. Reconvert the measured value to output it with decimal positions:
85 [V]
10
+ 8.5 V
Paramete
r bytes
2/3/4/5 Signal function Signal range Format 1) Tolerance
00
h
19 Parameter data in module are not overwritten
28
h
Voltage
measurement ±10 V −10.00
−27648 {0.01V}
{1
dec
}
+10.00
27648
S7
Two’s
complement
±0.1 % 2)
±0.2 % 3)
Min. Limit
values
Max.
−11.76 V
−32512
dec
+11.76 V
32511
dec
2B
h
Voltage
measurement ±10 V −10.00
−16384 {0.01V}
{1
dec
}
+10.00
16384
S5
Sum and sign
±0.1 % 2)
±0.2 % 3)
Min. Limit
values
Max.
−12.50 V
−20480
dec
+12.50 V
20480
dec
3Bh Voltage
measurement ±10 V −10.00
−16384 {0.01V}
{1
dec
}
+10.00
16384
S5
Two’s
complement
±0.1 % 2)
±0.2 % 3)
Min. Limit
values
Max.
−12.50 V
−20480
dec
+12.50 V
20480
dec
FF
h
Analog input deactivated
1) Format of the input data ( ¶ 13.1−6).
2) Tolerance of the input range at an ambient temperature of 25 °C.
3) Tolerance of the input range across the entire admissible temperature range.
