Parameterising 2/4xcounter module
Measuring the period (modes 17 and 19)
13
Parameter setting via PROFIBUS−DP
13.2
13.2.10
L
13.2−27 EDSPM−TXXX−9.0−11/2009
0 1 2 3
m
xxx
0 xxx
RES
START
STOP
CLK
Counter 0
Counter 1
Out0
Out1
n
epm−t091
Fig. 13.2−33 Signal characteristic of 2/4xcounter in the mode 17
OUT0 = HIGH Measuring process in progress
epm−t195
Fig. 13.2−34 Signal characteristic of 2/4xcounter in the mode 19
OUT0 = HIGH Gate open
Signal characteristic in mode 17
Signal characteristic in mode 19
